DESCRIPTION

AJ-ELECTRIC 4962PA Heavy-Duty 320 Amp Leece-Neville Replacement Alternator

New premium-quality 12-volt, 320-amp replacement alternator for Leece-Neville 4962PA heavy-duty charging systems.

Features four-point PAD mounting, self-exciting operation, internal voltage regulator, external cooling fan and heavy-duty brush-type construction.

Designed for commercial trucks, buses, emergency vehicles and other heavy-duty applications requiring the 4962PA alternator configuration.

Replaces Leece-Neville 4962PA, A0014962PA, 4962PGH and 4962PARM, along with selected OEM references.

New Unit — No Core Charge — One Year Warranty

Verify the original alternator number, mounting arrangement, charging-system requirements before ordering.

REPLACES / CROSS REFERENCE

Leece-Neville / Prestolite

• 4962PA
• A0014962PA
• 4962PARM
• 4962PAH
• A0014962PAH
• 4962PGH
• BLP4002H

International / Navistar

• 3588319C91
• 3588319C92
• ZLN4962PA

Mack

• 21080399
• 5034-4962PA
• 5034-A0014962PA

Other OEM

• Blue Bird 00098359
• Spartan Motors 0765-GG1
• Pierce 1193175
• Ferrara 310000019
• Cummins 4325304
• Delco Remy 8600298

SPECIFICATIONS

• Voltage: 12V
• Output: 320 Amp
• Series: Leece-Neville 4000 / 4900
• Mounting: Four-Point PAD Mount
• Rotation: Clockwise (CW)
• Excitation: Self-Exciting
• Regulator: Internal
• Fan: External
• Design: Brush Type
• Polarity: Negative Ground
• Positive Terminal: 5/16-18 UNC
• Negative Terminal: 3/8-16 UNC
• Shaft Diameter: 7/8 inch
• Lamp Driver: No
• Condition: New Replacement
• Core Charge: None
• Warranty: One Year

APPLICATIONS

Heavy-Duty Vehicles and Equipment

• Blue Bird buses
• International / Navistar trucks
• Mack trucks
• Spartan emergency vehicle chassis
• Pierce fire apparatus
• Ferrara fire apparatus
• Other commercial and emergency vehicles originally equipped with 4962PA
