AJ-ELECTRIC 2824LC / 2824JB Premium Heavy-Duty 160 Amp Leece-Neville Replacement Alternator

Premium-quality heavy-duty alternator designed as a direct replacement for Leece-Neville 2824LC, 2824JB and related J-180 alternators used in RV, motorhome, commercial and multi-battery charging applications.

14 Volt • 160 Amp • J-180 Mount • DUVAC / Multi-Battery System

Designed for motorhomes and RVs equipped with DUVAC dual/multi-battery charging systems, allowing the alternator to charge and maintain both chassis/starting batteries and coach/house batteries.

KEY FEATURES

• Original factory-rated 14 Volt, 160 Amp
• DUVAC / dual and multi-battery system compatible
• Internal solid-state low turn-on voltage regulator
• Internal rectifier
• Ignition excite
• Heavy-duty J-180 mounting
• Sealed high-speed bearings
• Steel inserts in heavy-duty mounting frames to help prevent wear and breakage
• External fan
• Bi-directional rotation
• Pre-installed 8-groove multi-groove pulley
• Computer tested for consistent output and reliability
• Includes simple hookup instructions
• Full Two-Year Warranty
• Assembled in the USA with U.S. and imported components

OEM & INTERCHANGE NUMBERS

Leece-Neville:
2824LC, LN2824LC, A0012824LC, 2825LC, A0012825LC, 2824J, 2824JB, A0012824JB, 90772, A001090772, 5052629013850, 90-04-7070, 90047070

Custom Chassis Inc: EL-039
Daimler Trucks North America: LN2824LC
Gillig Corp: 51-00179-008
International Truck & Engine: ZLN2824LC
Mack Trucks: 2742, 5034-2824LC
Monaco: A0012824LC, 2824LC
Newmar Dutch Star: A0012824LC, 2824LC
Dynasty / Diplomat: A0012824LC
Oshkosh Corporation: 6HA518
Prinoth: 110954522
Spartan Motors: 0499-GG1
Volvo North American Corp.: LN2824LC

LEECE-NEVILLE SERIES / MODELS

2500JB, 2600JB, 2700JB and 2800JB Series

Models: 2524JB, 2624JB, 2724JB, 2824JB, 2829JB

APPLICATIONS

Heavy-duty alternator used in RV, motorhome, recreational, industrial and medium/heavy-duty truck applications, including multi-battery systems requiring DUVAC charging.

Applications represented in the interchange information include:

Custom Chassis • Daimler Trucks North America • Gillig • International • Mack • Monaco • Newmar Dutch Star • Dynasty • Diplomat • Oshkosh • Prinoth • Spartan Motors • Volvo

TECHNICAL SPECIFICATIONS

Voltage: 14V
Output: 160 Amps
System Voltage: 12V
Mounting: J-180
Rectifier: Internal
Regulator: Internal
Excitation: Ignition Excite
Fan: External
Rotation: Bi-Directional
Mounting Bolt: 1/2-13 UNC
Positive Stud: 5/16-18 UNC
Negative Stud: 5/16-18 UNC
Pulley: 8-Groove Multi-Groove
Weight: 24 lbs. / 10.91 kg

DUVAC / MULTI-BATTERY CHARGING

This alternator is designed for multi-battery applications using a DUVAC dual-battery isolator system, commonly found in motorhomes and RVs. It is designed to charge and maintain both chassis/starting and coach/house battery systems.
